INTEGRATED AMD RADEON VEGA SERIES GRAPHICS IN RYZEN SERIES APU*
DIRECTX 12, PIXEL SHADER 5.0
SHARED MEMORY DEFAULT 2GB. MAX SHARED MEMORY SUPPORTS UP TO 16GB.**
DUAL GRAPHICS OUTPUT: SUPPORT HDMI AND DISPLAYPORT 1.4 PORTS BY INDEPENDENT DISPLAY CONTROLLERS
SUPPORTS HDMI 2.1 WITH MAX. RESOLUTION UP TO 4K X 2K (4096X2160) @ 60HZ
SUPPORTS DISPLAYPORT 1.4 WITH MAX. RESOLUTION UP TO 5K (5120X2880)@120HZ
SUPPORTS AUTO LIP SYNC, DEEP COLOR (12BPC), XVYCC AND HBR (HIGH BIT RATE AUDIO) WITH HDMI 2.1 PORT (COMPLIANT HDMI MONITOR IS REQUIRED)
SUPPORTS HDR (HIGH DYNAMIC RANGE) WITH HDMI 2.1
SUPPORTS HDCP 2.3 WITH HDMI 2.1 AND DISPLAYPORT 1.4 PORTS***
SUPPORTS 4K ULTRA HD (UHD) PLAYBACK WITH HDMI 2.1 AND DISPLAYPORT 1.4 PORTS
SUPPORTS MICROSOFT PLAYREADY
*ACTUAL SUPPORT MAY VARY BY CPU
**THE MAX SHARED MEMORY 16GB REQUIRES 32GB SYSTEM MEMORY INSTALLED.
***PICASSO SUPPORTS HDCP 2.2 WITH HDMI 2.0 PORT
AUDIO REALTEK ALC1200
7.1 CH HD AUDIO
SATA 3 6 PORT
RAID RAID 0, RAID 1, RAID 10 FOR SATA STORAGE DEVICES
M.22 X M.2 SOCKETS
1 X HYPER M.2 SOCKET (M2_1), SUPPORTS M KEY TYPE 2280 M.2 PCI EXPRESS MODULE UP TO GEN4X4 (64 GB/S) (WITH VERMEER, MATISSE) OR GEN3X4 (32 GB/S) (WITH CEZANNE, RENOIR AND PICASSO)**
1 X M.2 SOCKET (M2_2), SUPPORTS M KEY TYPE 2280 M.2 SATA3 6.0 GB/S MODULE AND M.2 PCI EXPRESS MODULE UP TO GEN3 X2 (16 GB/S)**
*M2_2 AND SATA3_5_6 SHARE LANES. IF EITHER ONE OF THEM IS IN USE, THE OTHER ONE WILL BE DISABLED.
